We are authorised dealers of Apar Industries from 2005-06 onwards. We keep ample stock and material is supplied along with Test Certificate from the manufacturer. In case of technical assistance, Apar, is more than willing to help.
APAR are pioneers in the field of manufacture of high performance Transformer Oils in India (environment friendly, higher oxidation stability, lower gassing tendency, ultra low levels of sulphur.
APAR is the world's fourth largest manufacturer and the largest manufacturer of Transformer Oils in India with approximately 50 % market share . Apar is the dominant supplier in power transformer sector (132 kV to 800 k V - AC & HVDC). They supply to OEMs, Utilities and Power Transmission & Distribution Companies.
No. | Characteristics | Test Mefliod | 15:335:1993 (Min) | 15:335:1993 (Max) |
---|---|---|---|---|
1. | Appearance | A representative sample of the oilshallbe examined in a 100 mm lhicklayer at 27°C | The Oil shall be clear and transparent and free from suspended matter or sediments | |
2. | Density at 29.5°C. glcm3 | IS:1448 (P-16)-1977 | - | 0.89 |
3. | Kinematic Viscosity, cSt. at 27°C | IS:1448 (P-25)-1976 | - | 27 |
4. | Interfacial Tension, N/M at 27°C | IS:6104-1971 | 0.04 | - |
5. | FlashPoint, Penslry-Marten (closed), °C | IS::1448 (P-21) - 1970 | 140 | - |
6. | Pour point, °C | IS::1448 (P-10) - 1970 | - | -6 |
7. | Neutralization Value a.Total Acidity. mg.KOH/gm b.Inorganic acidity/alkali |
IS::1448 (P-2) - 1967 | - | - |
8. | Corrosive Sulphur Copper Strip. 1!Hrs. @ 140°C | ANNEX-B | Non-Corrosive | Non-Corrosive |
9. | Electric Strength (Breakdown Voltage), KV(rms) a. New unfiltered oil b. After filteration |
IS-6792-1972 |
30 60 |
- |
10. | Dielectric dissipation factor (tanDelta) @ 90°C | IS-6262-1972 | - | 0.002 |
11. | Specific resistance (resistivity), ohm-cm a. At 90°C b. At 27°C |
IS-6103-1971 |
35 X 1012 1500 X 1012 |
- |
12. | Oxidation Stability(164Hrs @ 100°C) a. Neutralization Value, mgK0H/gm b. Total Sludge. Wt% |
ANNEX-C |
- | 0.40 0.10 |
13. | Accelerated ageing test (openbeaker method withcopper catalyst) 96Hrs @ 115°C a. Specific resistance Gesistivity). ohm-cm @ 27°C b. Specific resistance Gesistivity). ohm-cm @ 90°C c. Dielectric dissipation factor (tan delta) @ 90°C d. Total acidity, mg.KOH/gm e. Total sludge value |
IS:12177-1987 METHOD A IS:6103-1971 IS:6103-1971 IS:6262-1971 IS:1448 (P-2) - 1967 ANNEX A of 12177 |
2.5 X 1012 0.2 X 1012 - - - |
- - - - 0.20 0.05 0.05 |
14. | Presence ofoxidation inhibitor | IS:13631-1992 | The oil shall not contain antioxidant additives | The oil shall not contain antioxidant additives |
15. | Water content, ppm | IS:13567-1992 | - | 50 |
POWEROIL TO 20 is an Uninhibited Transformer Oil meeting IEC 296 Class I : 1982 Standard Specification.
No. | Characteristics | Unit | Test Mefliod | 15:335:1993 (Min) | 15:335:1993 (Max) |
---|---|---|---|---|---|
1. | Appearance | - | Representative sample of the oil shall be examined in transmitted light under a thickness of 10 cm at ambient temperature | Clear free from sediment and suspended matter | |
2. | Density at 20° C | Kg / dm 3 | ISO 3675 | - | 0.895 |
3. | Kinematic Viscosity at 40° C at 20° C at -15° C |
Mm 2 / sec |
ISO 3104 | - | 16.5 |
4. | Flash Point, PMCC | ° C | ISO 2719 | 140 | - |
5. | Pour Point | ° C | ISO 3016 | - | - 30 |
6. | Inter Facial Tension at 25° C | N / m | ISO 6275 | 0.04 | - |
7. | Neutralization Value | mg KOH/ gm | 7.7 of IEC 296 | - | 0.03 |
8. | Water Content , Bulk / Drum | ppm | IEC 733 | - | 30 / 40 |
9. | Breakdown Voltage As Delivered / After Treatment |
kV |
IEC 156 |
30 / 50 |
- - |
10. | Dielectric Dissipation Factor (Tan δ )at 90° C & 40 to 60 Hz | - | IEC 247 | - | 0.005 |
11. | Corrosive Sulphur Copper Strip, 140° C, 19 Hrs | - | ISO 5662 | Non Corrosive | |
12. | Anti Oxidant Additives | % | IEC 666 | Not Detectable | |
13. | Oxidation Stability at 100° C, 164 Hrs Neutralization Value Sludge |
mg KOH /gm % |
IEC 74 |
- | - 0.4 0.1 |
POWEROIL TO 10 is an Uninhibited Transformer Oil meeting IEC 296 Class II : 1982 Standard Specification. It also meets the ASTM D 1275 B Test requirement for Corrosive Sulphur.
No. | Characteristics | Unit | Test Mefliod | 15:335:1993 (Min) | 15:335:1993 (Max) |
---|---|---|---|---|---|
1. | Appearance | - | Representative sample of the oil shall be examined in transmitted light under a thickness of 10 cm at ambient temperature | Clear free from sediment and suspended matter | |
2. | Density at 20° C | Kg / dm 3 | ISO 3675 | - | 0.895 |
3. | Kinematic Viscosity at 40° C at 20° C at -30° C |
Mm 2 / sec |
ISO 3104 | - | 11 25 18 |
4. | Flash Point, PMCC | ° C | ISO 2719 | 130 | - |
5. | Pour Point | ° C | ISO 3016 | - | - 45 |
6. | Inter Facial Tension at 25° C | N / m | ISO 6275 | 0.04 | - |
7. | Neutralization Value | mg KOH/ gm | 7.7 of IEC 296 | - | 0.03 |
8. | Water Content , Bulk / Drum | ppm | IEC 733 | - | 30 / 40 |
9. | Breakdown Voltage As Delivered / After Treatment |
kV |
IEC 156 |
30 / 50 |
- - |
10. | Dielectric Dissipation Factor (Tan δ )at 90° C & 40 to 60 Hz | - | IEC 247 | - | 0.005 |
11. | Corrosive Sulphur Copper Strip, 140° C, 19 Hrs Copper Strip, 150° C, 48 Hrs |
- | ISO 5662 ASTM D 1275 B |
Non Corrosive Non Corrosive |
|
12. | Anti Oxidant Additives | % | IEC 666 | Not Detectable | |
13. | Oxidation Stability at 100° C, 164 Hrs Neutralization Value Sludge |
mg KOH /gm % |
IEC 74 |
- | - 0.4 0.1 |
